CLY High Speed Cable Making Machine

Application
CLY cable making machine is used for the production of medium low voltage cables, communication cables, control cables, mining cables and many other cables. It is a perfect alternative to traditional type of 1250/1000/1600/ (1+1+3) cable making machine.

Parameters

Bobbin size (mm)	Cable core O.D. （mm）	Max. Load capacity （kg）	Max. rotation speed（rpm）	Max. rotation speed with back-twisting（r/min）	Motor power （kw）	Back-twisting motor power （kw）
Ø1000	Ø 5.0~20	2000	60	150	44	11
Ø 1250	Ø 6.0~25	3000	50	120	55	15
Ø 1600	Ø 10.0~35	4000	40	100	75	18.5
